CAB rear camera cable harness (CAB-01 to CAB-20)

  • CAB rear camera cable harness for tractor-to-trailer camera and power runs
  • CAB-01 to CAB-20 share the same construction; only the ordered length differs
  • 4-pin aviation connector in the standard female-to-male configuration
  • Copper video shield, aluminium-foil shielding and separate power conductors

Send the vehicle type, quantity and market — we reply with a configuration and price within 24 hours.

CAB selling points

One foam-cable construction, eight model lengths

CAB-01 through CAB-20 use the same four-pin foam-cable construction and jacket options. The model number identifies the nominal ordered length, so the family starts with eight clear length choices rather than near-duplicate product descriptions.

Cable construction
30 x 0.1 mm copper video shield; aluminium-foil shielding; 10 x 0.12 mm copper wires for B+, B- and audio; 3 cotton threads; PE video insulation.
4-pin definition
1 B+ | 2 B- | 3 audio | 4 video. Confirm the vehicle-side definition before ordering.
Jacket / outer diameter
Professional version OD 5.5 mm; standard version OD 4.5 mm.
Length and long-run evidence
Nominal model lengths run from CAB-01 at 1 m to CAB-20 at 20 m. The supplier source labelled 85m test good shows a live monitor; an 80 m installed system still requires confirmation of the complete camera, monitor, power and harness.
Approved CAB main product view selected in the image order
01. Product identity

CAB rear camera cable harness for tractor-to-trailer camera and power runs

CAB-01 to CAB-20 exact-model family test set showing multiple completed cable coils
02. Family test-set evidence

CAB-01 to CAB-20 share the same construction; only the ordered length differs

Approved CAB product view showing the male and female four-pin aviation connectors
03. 4-pin aviation connector

4-pin aviation connector in the standard female-to-male configuration

01

85 m supplier test evidence

Sound available in the player

Sound is available in the player. This 4.5-second source clip retains its original low-level ambient audio and shows the monitor during the supplier set labelled 85m test good.

02

Cable construction demonstration

Sound available in the player

Sound is available in the player. This 18-second source excerpt retains the supplier audio from the construction demonstration described in the cable-detail PDF.

CAB product features

  • CAB rear camera cable harness for tractor-to-trailer camera and power runs
  • CAB-01 to CAB-20 share the same construction; only the ordered length differs
  • 4-pin aviation connector in the standard female-to-male configuration
  • Copper video shield, aluminium-foil shielding and separate power conductors
  • Length, connector combination, pin-out and packaging are confirmed per order

Ordering notes

Points to confirm before production so the unit arrives ready to fit.

  • Confirm the required length before ordering
  • Confirm the connector combination and pin-out
  • Confirm whether a waterproof boot or protective sleeve is required
  • Confirm quantity, packaging and printing requirements
