JPC-176 side-view camera C37K (1080P AHD / 135° ultra-wide angle / IP69K structural waterproof / in-vehicle BSD blind

Name: JPC-176 — JPC-176 side-view camera C37K (1080P AHD / 135° ultra-wide angle / IP69K structural waterproof / in-vehicle BSD blind
Brand: JFA-CAM

JPC-176 side-view camera C37K (1080P AHD / 135° ultra-wide angle / IP69K structural waterproof / in-vehicle BSD blind zone)

Request a Quote Email about JPC-176

Key features

Streamax's cameras use the same foundry and the same set of vehicle-specific processes and testing standards
This is not a general security camera modification: the sensor, lens, structural waterproofing, and wiring harness are all made according to vehicle working conditions
Similar products have been used in batches in overseas fleet safety systems (BSD blind spot detection), and they run on this platform
Small form factor side camera designed for Blind Spot Detection (BSD) - mounted on the side of the car to see the blind spot
Ultra-wide-angle 170°(D) / 135°(H) / 100°(V), 2.2mm lens: taking in the blind spots from the sides to the sides and rear of the car into the frame at once
Combined with the MDVR/AI box, it can provide blind spot reminders: remind the driver when turning right, changing lanes, or pulling over
190g small body, unobtrusive side mounting, easy wiring
Adaptation: truck/trailer side blind area, bus right side blind area, special-purpose vehicles, fleet BSD system
1080P AHD output, 1920(H)×1080(V), clear picture
Default 2053 + 8536H platform
Adaptive digital noise reduction; digital WDR
Automatic white balance (automatic tracking), automatic backlight compensation, Gamma 0.45
Support mirror switching (Mirror): side mounting/rear mounting can be adjusted to full image or mirror image
Video output 1.0Vp-p 75Ω, directly connected to vehicle monitor/MDVR
IP69K structural waterproofing: sealed by structure, not filling the ball with glue, waterproof warranty for at least 2 years
Advantages of not filling with glue: better heat dissipation, later repairability, and higher long-term reliability
Professional vehicle IR-CUT (Professional vehicle IR CUT)
Minimum illumination 0 Lux (infrared on), night vision distance 10 m
After using IR-CUT: The picture is no longer red and purple under the bright sun during the day, and it is no longer blurry at night (compared to the old version)
Small body, few screws, compact structure, guaranteed vehicle vibration damping performance
4-pin aviation female connector (Pin map as per drawing), DC 12V power supply
Power consumption <3W, weight about 190g
Working temperature -40~+70°C, humidity 10-90%
Standard aviation connector, equipped with MDVR plug and play

Ordering notes

Points to confirm before production so the unit arrives ready to fit.

Confirm the chipset: 2053 + 8536H is standard.
Confirm 1080P version and 4-pin aviation female connector (Pin map as per drawing)
Confirm the lens angle and application: This model is designed for side view/BSD (FOV H 135°), please specify other angles in advance
Confirm the wire length (default 0.5m tail wire, 1m / 5m / 10m can be custom)
Confirm whether an IP69K test report needs to be provided with the goods
Confirm the picture mode: positive image / mirror image (this model supports Mirror switching)
Confirm the installation location and bracket (side of the car body/under the rearview mirror), and avoid the fuel tank opening, exhaust pipe and tire mud area
Default specifications: 2053 + 8536H solution / 135° field of view / PAL system / without reversing auxiliary line (no park line); no wide dynamic range (WDR) function, if you need other angles or NTSC, please explain in advance
Confirm quantity, packaging (colour box or neutral box) and printing requirements in advance.

Installation & usage

Voltage, wiring, sealing and maintenance guidance for the installer.

Confirm the voltage (DC12V) before wiring. Do not connect the positive and negative poles reversely
Route and secure the cable away from the engine and other hot surfaces, and clear of sharp sheet-metal edges.
Tighten the connector and fit the waterproof boot to keep water out.
Tighten the screws once the angle is set.
Working temperature -40°C~+70°C, storage -30°C~+80°C, humidity below 95%
IP69K structure is waterproof, but when washing the car, avoid direct high-pressure water gun directed at the lens and connector for a long time
The side mounting position avoids the fuel tank opening, exhaust pipe and tire mud-slinging area
