Main image and detail shots of the BMW MGU (HCJ-8802).
BMW MGU decoder (HCJ-8802 / factory screen with camera)
Send the vehicle type, quantity and market — we reply with a configuration and price within 24 hours.
Key features
- [Specialized for special vehicles] Before placing an order, you must confirm: model + year + whether the host system is MGU (ID7). BMW main units are divided into CCC / CIC / NBT / EVO / MGU. MGU is a new system after model 21, so it cannot be used if you admit the mistake
- BMW MGU (ID7) system dedicated decoder, model HCJ-8802
- Covering 21-22 BMW models (corresponding to MGU system)
- Display the reversing image/front view/360 panorama on the original iDrive large screen without changing the screen
- Retain the factory harness’s iDrive system and all factory functions
- Losslessly transfer the factory harness LVDS and power wiring harness without breaking the wires
- Supports recorder switching (press and hold the factory harness button after setting according to the manual to enter)
- There is also a pure electric iX3 (MGU system) solution on the same platform, please confirm by model
Ordering notes
Points to confirm before production so the unit arrives ready to fit.
- Model + year + host system (must be MGU / ID7) must be confirmed by the customer
- Confirm the factory harness screen size (10.25 / 12.3 inches) and whether it has a touch screen
- Confirm which function it feeds: reversing view, front view, 360 panoramic, CarPlay or dashcam switching.
- Confirm whether a camera, extension cable and bracket are required.
- Confirm whether the customer's market has vehicle inspection requirements.
- Confirm quantity, packaging and printing requirements in advance.
Installation & usage
Voltage, wiring, sealing and maintenance guidance for the installer.
- Always work with the power off, and protect the factory centre console and screen.
- Connect the factory head unit's LVDS plug to the decoder's LVDS-OUT, and plug the adapter harness back into the head unit.
- Check the DIP switches and harness before applying power.
- After installation, test whether the factory harness's iDrive, reversing screen, factory radar, and iDrive knob are normal
- Keep the original parts so the vehicle can be restored and warranty work is straightforward.
- Route and secure the cable clear of hot surfaces and airbag zones.
